Itu juga kadang-kadang disebut National Pipe Thread, NPTF (F for Fuel), American Standard Taper, atau sekadar "pipa".
Jenis adaptor NPT: adaptor pria atau wanita
Standar Produk: ISO 11926-3, SAE J514 dan BS 5200
Ukuran grafik ukuran adaptor NPT adalah 1/8 NPT, 1/4 NPT, 3/8 NP, 1/2 NPT, 3/4 NPT, 1 "NPT dll.
Bahan: baja karbon, stainless steel atau paduan tembaga
Bentuk adaptor pas NPT: lurus, Siku, Tee, Salib, Peredam dll.
NPT fitting adapter untuk swivel fitting, metric adapter, bspp adapter, sae adapter dll.
Dimensi adaptor BNUN NPT MALE / NPSM FEMALE / NPT MALE sebagai berikut:
PAR T TIDAK | THREA D | DIMENSI S | ||||||||
E | F | G | SEBUAH | B | C | S 1 | S 2 | |||
BNUN-0 4 | Z1 / 4 "X1 8 | 1/4 "X1 8 | Z1 / 4 "X1 8 | 25. 5 | 4. 6 | 25. 5 | 1 4 | 1 9 | ||
BNUN-06-04-0 6 | Z3 / 8 "X1 8 | 1/4 "X1 8 | Z3 / 8 "X1 8 | 3 1 | 4. 6 | 3 1 | 1 9 | 1 9 | ||
BNUN-04-06-0 4 | Z1 / 4 "X1 8 | 3/8 "X1 8 | Z1 / 4 "X1 8 | 25. 5 | 6 | 25. 5 | 1 4 | 2 2 | ||
BNUN-0 6 | Z3 / 8 "X1 8 | 3/8 "X1 8 | Z3 / 8 "X1 8 | 3 1 | 6 | 3 1 | 1 9 | 2 2 | ||
BNUN-08-06-0 8 | Z1 / 2 "X1 4 | 3/8 "X1 8 | Z1 / 2 "X1 4 | 36. 7 | 6 | 36. 7 | 2 2 | 2 2 | ||
BNUN-06-08-0 6 | Z3 / 8 "X1 8 | 1/2 "X1 4 | Z3 / 8 "X1 8 | 3 1 | 7. 5 | 3 1 | 1 9 | 2 7 | ||
BNUN-0 8 | Z1 / 2 "X1 4 | 1/2 "X1 4 | Z1 / 2 "X1 4 | 37. 3 | 7. 5 | 37. 3 | 2 2 | 2 7 | ||
BNUN-1 2 | Z3 / 4 "X1 4 | 3/4 "X1 4 | Z3 / 4 "X1 4 | 43. 5 | 8. 9 | 43. 5 | 2 7 | 3 2 | ||
BNUN-1 6 | Z1 "X11. 5 | 1 "X11. 5 | Z1 "X11. 5 | 5 0 | 10. 5 | 5 0 | 3 3 | 4 1 | ||
BNUN-2 0 | Z1.1 / 4 "X11. 5 | 1.1 / 4 "X11. 5 | Z1.1 / 4 "X11. 5 | 6 0 | 11. 2 | 6 0 | 4 1 | 5 0 | ||
BNUN-2 4 | Z1.1 / 2 "X11. 5 | 1.1./2"X11. 5 | Z1.1 / 2 "X11. 5 | 5 9 | 11. 2 | 5 9 | 4 8 | 5 5 | ||
BNUN-3 2 | Z2 "X11. 5 | 2 "X11. 5 | Z2 "X11. 5 | 73. 5 | 11. 2 | 73. 5 | 6 3 | 7 0 | ||
