Itu juga kadang-kadang disebut National Pipe Thread, NPTF (F for Fuel), American Standard Taper, atau sekadar "pipa".
Jenis adaptor NPT: adaptor pria atau wanita
Standar Produk: ISO 11926-3, SAE J514 dan BS 5200
Ukuran grafik ukuran adaptor NPT adalah 1/8 NPT, 1/4 NPT, 3/8 NP, 1/2 NPT, 3/4 NPT, 1 "NPT dll.
Bahan: baja karbon, stainless steel atau paduan tembaga
Bentuk adaptor pas NPT: lurus, Siku, Tee, Salib, Peredam dll.
NPT fitting adapter untuk swivel fitting, metric adapter, bspp adapter, sae adapter dll.
Dimensi adaptor 7NU -S NPT FEMALE / NPSM FEMALE 60 ° CONE sebagai berikut:
PA RT NO . | T HR EA D | DIM E N S I O NS | |||||
E | F | B | L. | S 1 | S 2 | ||
7NU - 02S | Z 1/8 " X 27 | 1/8 " X 27 | 3.5 | 24 | 17 | 15 | |
7NU - 04 - 02S | Z 1/4 " X 18 | 1/8 " X 27 | 3.5 | 29 | 19 | 15 | |
7NU - 04S | Z 1/4 " X 18 | 1/4 " X 18 | 4.6 | 31.5 | 19 | 19 | |
7NU - 04 - 06S | Z 1/4 " X 18 | 3/8 " X 18 | 6 | 33 | 19 | 22 | |
7NU - 06S | Z 3/8 " X 18 | 3/8 " X 18 | 6 | 34 | 22 | 22 | |
7NU - 06 - 08S | Z 3/8 " X 18 | 1/2 " X 14 | 7.5 | 34 | 22 | 27 | |
7NU - 08 - 06S | Z 1/2 " X 14 | 3/8 " X 18 | 6 | 39 | 30 | 22 | |
7NU - 08S | Z 1/2 " X 14 | 1/2 " X 14 | 7.5 | 41 | 30 | 27 | |
7NU - 12S | Z 3/4 " X 14 | 3/4 " X 14 | 8.9 | 44 | 36 | 32 | |
7NU - 16S | Z 1 " X 11.5 | 1 " X 11.5 | 10.5 | 51.5 | 41 | 41 | |
7NU - 20S | Z 1.1 / 4 " X 11.5 | 1.1 / 4 " X 11.5 | 11.2 | 55 | 50 | 50 | |
7NU - 24S | Z 1.1 / 2 " X 11.5 | 1.1 / 2 " X 11.5 | 11.2 | 55.5 | 60 | 55 | |
7NU - 32S | Z 2 " X 11.5 | 2 " X 11.5 | 11.5 | 57 | 70 | 70 | |
