Kategori produk: SAE 37 deg flare fittings adapter
Bahan: baja karbon, stainless steel atau paduan tembaga
5JT JIC MALE 74 ° CONE / BSPT FEMALE Diagram dimensi sebagai berikut:
PA RT NO . | T HR EA D | DIM E N S I O NS | |||||
E | F | SEBUAH | L. | S 1 | |||
5 J T - 04 - 02 | 7/16 " X 20 | Rc 1/8 " X 28 | 14 | 30 | 14 | ||
5 J T - 04 | 7/16 " X 20 | Rc 1/4 " X 19 | 14 | 35.5 | 19 | ||
5 J T - 06 - 04 | 9/16 " X 18 | Rc 1/4 " X 19 | 14 | 35.5 | 19 | ||
5 J T - 06 | 9/16 " X 18 | RC3 / 8 " X 19 | 14 | 36.5 | 22 | ||
5 J T - 08 - 06 | 3/4 " X 16 | RC3 / 8 " X 19 | 16.7 | 39.5 | 22 | ||
5 J T - 08 | 3/4 " X 16 | R c 1/2 " X 14 | 16.7 | 45.5 | 27 | ||
5 J T - 10 - 08 | 7/8 " X 14 | R c 1/2 " X 14 | 19.3 | 48 | 27 | ||
5 J T - 12 | 1.1 / 16 " X 12 | R c 3/4 " X 14 | 22 | 52.5 | 36 | ||
5 J T - 16 | 1,5 / 16 " X 12 | R c 1 " X 11 | 23 | 59.5 | 41 | ||
